Product specifications

ContraTherm® C55 has been effectively used in subsea applications for over 25 years.  The system is designed specifically for thermal insulation applications for subsea production equipment.  Based upon a phenolic resin system, it provides the ultimate in temperature resistance among polymeric materials and has proven hot/wet performance.

  • Cold curing properties. Ideal for applying within or over thin wall housing
  • Thermal conductivity – wet (using ASTM test)
  • Maximum service temperature +185°C
  • Low shrinkage ensures tight production tolerances can be achieved
  • Thermal conductivity – dry ( using ASTM test)
  • ISO 12736 wet thermal insulation systems.

Tested for use in the toughest conditions

Chemical resistance

Resistant to seawater, oil, solvents, acids, and chemicals.

Track record

Used for over 25 years with no in-service failures

Maximum service depth

Tested to provide effective insulation at over 3,000MSW.
