Product specifications

ContraFlame® combined cryogenic spill protection (CSP) and passive fire protection (PFP) has been tested for 60 minutes jet fire protection and two hour cryogenic spill protection.

  • Incorporates phenolic fibreglass reinforced tiles and our ContraFlame® C50 thermal insulation material
  • A total system thickness of just 34mm
  • The system can withstand 7Mpa of compression load
  • The system is designed for continuous use at operating temperatures from -196°C to +185°C
  • Provides both Cryogenic Spill Protection and jet fire protection for 60 minutes
  • Designed for use on exposed deck areas and all vertical exposed steelwork on FLNG’s.
Download technical data sheet ()

Tested for use in the toughest conditions

Installation

Quick and easy to install because of the tile size and shape.

Time efficient

Damaged tiles can be easily replaced, minimising maintenance time.

Tried and tested

Tested for 60 minutes Jet Fire protection and 2 hour cryogenic spill protection.

Request a quote

Product applications

AIS has a range of passive fire protection solutions that can be used in applications worldwide to protect vessels and infrastructure onshore and offshore.

Bulkhead protection

Passive fire and blast protection and lightweight integrated insulation systems.
